Dimensions - Detector:

Length: 657 mm (folded up)

Max. overall length: 1,677 mm

Width: 97 mm

Height: 253 mm

Dimensions - Search head:

Oval, 210 x 285 mm

Dimensions - Soft case:

720 x 340 x 150 mm (H x W x D)

Weight:

2.2 kg without batteries

2.6 kg complete with batteries

2.5 kg soft case

Waterproof - Electronics

and search head:

IP 68, 2 m, 30 minutes

Storage temperature

(without batteries):

- 57 °C to +71 °C

- 135 °F to +160 °F

Permissible ambient

temperature range:

- 37 °C to +71 °C

- 99 °F to +160 °F

Power supply:

3 x 1.5 V alkaline battery

3 x 1.2 V NiMH rechargeable batteries

Battery size:

IEC LR/HR 20 (according to ANSI STD, size “D”)

Battery lifetime alkaline battery

(1.5 V, VARTA LONGLIFE Power):

> 40 h at an ambient temp. of +20 °C (+68 °F)

Battery lifetime NiMH rechargeable battery (1.2 V, ANSMANN-10000 mAh):

> 30 h at an ambient temp. of +20 °C (+68 °F)

Mean time between failures (MTBF):

MIL-HDBK-217F N2 and ANSI/VITA 51.1-2013 (R2018) NPRD-2011 for non-electronic components

EMV/CE certifications:

ETSI EN 303 454 V1.1.1:2018-01 DIN EN 50364:2019-05

ETSI EN 301 489-1 V2.2.3 DIN EN 55032:2016-02

DIN EN 61000-4-2:2009-12 DIN EN 61000-4-3:2011-04 DIN EN 62368-1:2021-05

MIL-Standard certification:

MIL-STD 810H Method 501.7, Procedure I - High Temperatures , Storage MIL-STD 810H Method 501.7, Procedure II - High Temperatures, Operation MIL-STD 810H Method 502.7, Procedure I - Low Temperatures, Storage MIL-STD 810H Method 502.7, Procedure II - Low Temperatures, Operation MIL-STD 810H Method 503.7, Procedure I-C - Thermal Shock

MIL-STD-810H Method 506.6, Procedure I - Rain

MIL-STD-810H Method 512.6, Procedure I - Submersion

MIL-STD-810H Method 514.8, - Oscillation Broadband Noise

MIL-STD-810H Method 516.8, - Drop Test

MIL-STD-810G Method 505.5, Procedure II - Solar Radiation

(continuous test solar radiation)

IMAS certification:

CWA 14747-1:2003-06-01

Additional certifications:

IEC 60068-2-11:2020

IEC 60068-2-78:2012

IEC 60529 - Protection type test IP68 DIN EN 60068-2-27:2010-02

DIN EN 60068-2-1:2008-01/ -2-2:2008-05
